Containment Cabin
| Applications | Laboratory, For Clean Rooms |
| Other Characteristics | Negative Pressure |
| Configuration | Walk-In |
| Function | Containment, Chemical, Sampling, Weighing |
The CrossFLOW CFU module offers a solution for powder containment during dosing, weighing, and sampling operations.input:
output:Initially designed to preserve the pharmaceutical and chemical industriesThe CrossFLOW CFU module is appropriate for use at any point during the manufacturing process where powders may be accidentally released into the environment, thereby maintaining the integrity of safe and hygienic manufacturing processes.
input:
output:The CrossFLOW Powder Containing modules ensure safe conditions and protection during all operational processes by eliminating the risk of cross-contamination for the operators, the products handled, and the inner and external environment.
A slight negative pressure is generated by the air flow pattern, which isolates the booth from the surrounding area and eliminates any risk of contamination to the external environment. This is the fundamental working principle.input:
output:Technical Specification
Housing:The body structure is entirely composed of press-bent metal sheets with a radius of 3 mm made of stainless steel AISI 304L 4B (Scotch Brite finishing) to facilitate easy cleaning and a roughness of less than 0.8 Ra.input:
output:Filter:Protective grids for H14 HEPA filters are constructed from AISI 304L stainless steel. The prefiltration stage is comprised of G3 filtration cells (AISI 304L stainless steel) that are equipped with a quick-release system and F9 dihedral bag filters that adhere to EN 779. Filtration stage that includes a main and exhaust H14 HEPA filter of the DUG type, a volume control dumper, and a DEHS test port, with a typical efficiency of 99.995% MPPS in accordance with CEN EN 1822. Technical material is utilized to construct a bag plenum that facilitates optimal airflow.input:
output:Ventilation:Electronically commutated double inlet motorblowers of the ECM DDTAC type are employed to provide ventilation.
