Medical equipment sourcing
Computer Cart Medical Panel Pc
Reference: 1146923Healthcare It, Telemedicine
| Processor | Intel® Celeron®, Intel® Core I5, Intel® Core I7, Intel® Core I3 |
| Resolution | Full Hd |
| Other Characteristics | Fanless, With Touchscreen, Waterproof, Hdmi, Antibacterial, Antimicrobial, With Usb |
| Applications | Surgery, Operating Room, For Computer Carts |
| Configuration | All-In-One |
| Hdd Capacity | Ssd 128 Gb |
| Display Size | 21.5" |
| Technology | Rfid Technology |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Internal Power SupplyOptional Hot-Swappable Batteries X3 Medical Latest EN 60601-1 & 60601-1-2 Certifications
Fanless Design with Reliable Thermal Solution
Dual storage M.2 SSD & 2.5” drive
Hospital White Plastic Housing
Optional 4KV Isolated 1X LAN, 1X COM module
Support PCIex4 Expansion Slot
Optional DICOM Part 14 Module
Optionsinput:
output:1. Webcam with 5 Megapixels and Auto Focus2. TPM 2.0 module3. Smart Card Reader at the side or CAC/PIV Reader (FIPS-201) (different rear housing)4. AG Film5. RFID (13.56MHz)6. Bluetooth + Wifi WLAN with dual antennas
7. M.2 Type 2280 Module8. 2.5" SATA3 Storage9. Equipotential Terminal Pin10. 4K SC710N1 12G SDI Capture Card or Full HD Capture Card11 USB 2.0 x 2 at the side (distinct rear housing)12. 5V1A Power Jack (Standard Type)13. DICOM Part 14 Compliance (light sensor cannot coexist)14. One DR-202 Series integrated UPS battery
15. Isolated 4KV module (4kV iso gigaLAN x 1, 4kV iso COM x 1)16. External device power output card with a 30 watt rating17. USB 5/6 (USB 2.0 cannot coexist with side USB)…Customized1. Glass that is tempered
2. Touch Panel with Anti-glare Coating
3. 5V1A Output is supported by COM ports
Fanless Design with Reliable Thermal Solution
Dual storage M.2 SSD & 2.5” drive
Hospital White Plastic Housing
Optional 4KV Isolated 1X LAN, 1X COM module
Support PCIex4 Expansion Slot
Optional DICOM Part 14 Module
Optionsinput:
output:1. Webcam with 5 Megapixels and Auto Focus2. TPM 2.0 module3. Smart Card Reader at the side or CAC/PIV Reader (FIPS-201) (different rear housing)4. AG Film5. RFID (13.56MHz)6. Bluetooth + Wifi WLAN with dual antennas
7. M.2 Type 2280 Module8. 2.5" SATA3 Storage9. Equipotential Terminal Pin10. 4K SC710N1 12G SDI Capture Card or Full HD Capture Card11 USB 2.0 x 2 at the side (distinct rear housing)12. 5V1A Power Jack (Standard Type)13. DICOM Part 14 Compliance (light sensor cannot coexist)14. One DR-202 Series integrated UPS battery
15. Isolated 4KV module (4kV iso gigaLAN x 1, 4kV iso COM x 1)16. External device power output card with a 30 watt rating17. USB 5/6 (USB 2.0 cannot coexist with side USB)…Customized1. Glass that is tempered
2. Touch Panel with Anti-glare Coating
3. 5V1A Output is supported by COM ports
