Compact Laboratory Peristaltic Pump

Reference: 683775Laboratory Infrastructure
Other CharacteristicsCompact

Associated tags

No tags assigned
manage_search

Product fit review

Compare the available product information with your application and purchasing requirements.

description

Documentation request

Ask which specifications, manuals, or commercial documents are available for review.

support_agent

Supplier coordination

Discuss quantity, destination, packaging, and timing before confirming suitability.

Product information

Product summary

This peristaltic pump is optimal for the effortless transportation of any type of media. This model's pump drive enables the transition between a single-channel and multi-channel pump head. It can also be conveyed in an anti-clockwise direction by simply flipping the switch.input:
output:A flow rate of 0.83 - 861 ml/min for the single-channel and 0.005 - 364 ml/min for the multi-channel pump head is guaranteed, contingent upon the adapted pump head. With a control accuracy of ± 5%, the Core 120 conveys at a speed range of 10 to 120 rpm.input:
output:Operation on Multiple Channels

Boost your throughput by operating up to 12 individual cassettes on a single pump drive and pump head system.

In a single operation, the flow rate can be adjusted by separating metering into multiple vessels with varying feed rates using different tubing dimensions.Save time: the tubing can be replaced in a matter of seconds.You have the option of selecting 8-roller pump heads for low pulsation in addition to standard pump heads, which are equipped with a 4-roller system.

Cassettes can be replaced effortlessly, even while in operation; there are no limitations.Simple adjustments and modifications to cassettes can be accomplished by simply clicking them into place.There is no requirement to acquire an additional pump drive: Select the head/cassette configuration that aligns with your application requirements and upgrade your single-channel pump drive with a single adaptor for multi-channel use.
