Co2 Probe

The HLX871 digital CO2 probe has a broad measuring range of up to 10,000 ppm. The probe is IP65-protected and has a diameter of only 18.5 mm. The CO2 probe EE871 is an optimal solution for demanding HVAC applications, data loggers, or handheld devices due to these features.

The CO2 sensor's digital interface enables the effortless retrieval and processing of measurement values, as well as a distinctive configuration and adaptation to the application. The CO2 probe HLX871 is the ideal solution for battery-powered devices due to the ability to reduce the average power consumption to less than 60μA through the adjustable measuring interval.

The CO2 probe HLX871 employs infrared technology (NDIR) as its measuring principle. The CO2 probe is maintenance-free due to the patented auto-calibration, which does not necessitate a consistent supply of fresh air. Auto-calibration effortlessly mitigates the effects of aging. The CO2 sensor is safeguarded from contamination by a replaceable PTFE filter. There is an assurance of exceptional stability over the long term.

The CO2 probe HLX871's greatest strength is its application in custom OEM solutions. You may either submit your inquiry to us or consult with your sales representative. Our sensor specialists will provide you with guidance.input:
output:Technical dataThe measuring range is 0–2000, 5000–10,000 ppm.

Outputs a digital E2 interface.Precision±(50ppm + 2% of measuring value) for 0...2000ppm±(50ppm + 3% of measuring value) for 0...5000ppm±(100ppm + 5% of measuring value) for 0...10000ppm

Provide a DC voltage of 4.75 to 7.5 volts
