Climate Chamber

In order to underscore the correlation with numerous conventionally conducted test conditions, this product is equipped with two control methods (saturation and unsaturation) and three exhaust modes (slow cooling with humidity maintained mode, cooling with moisture maintained mode, and rapid exhaust mode). The control mode and exhaust mode can be chosen in accordance with the purpose of the test.



Three types of operation modes exist.input:
output:It is equipped with a cleaning operation mode, in addition to a fixed-value operation mode and a programmed operation mode that enables the registration of a total of 1500 steps within a maximum of 150 operation patterns.input:
output:
Touchscreen display with color capabilitiesinput:
output:
A color touch panel has been installed, which incorporates a variety of button operations, numerical values and graphs, and alarm messages.input:
output:Particularly relevant to the chamberinput:
output:A dual vessel structure and round shape that can demonstrate exceptional performanceinput:
output:The test chamber and the steam generator are autonomous in the dual vessel structure of the PC-R9 series HAST chambers. The dual vessel structure is capable of conducting more stable test evaluations than the single vessel structure due to the fact that it reduces the mutual temperature influence between a test chamber (dry bulb) and a steam generator (wet bulb) while optimizing the test chamber's effective square footage. Each vessel employs a round vessel that is dependable in terms of temperature distribution and strength.input:
output:Chamber that is resistant to stainsinput:
output:The chamber's surface has been electrolytically polished to achieve a smooth and glossy appearance, as it is constructed from stainless steel (SUS316L).
