Clean Room Shower
Reference: 747565
Laboratory Infrastructure
| Options | Air, Tunnel Type |
| Application | For Clean Rooms, Decontamination |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Standard-Profile Straight-Through Air Showers are capable of rapidly and efficiently eliminating particles that would otherwise be transported into your cleanroom. Rugged construction and adjustable, high-velocity air jets are hallmarks of our decontamination air showers.Features: The painted cold-rolled steel shell is durable and cleanroom-approved.Color HMI Touch Screen
Epoxy or Urethane Sealant
(2) Safety glass doors with hydraulic door closers and anodized aluminum framesAnodized Aluminum Fixed Bottom Door Sweeps(2) LED Recessed Light Fixtures with Wall Switch, (4) LED Recessed Light Fixtures with Wall Switch for Double Door Models(64) Anodized aluminum nozzles that can be adjustedAdjustable anodized aluminum ceiling nozzles (four)(4) Wall Panels with Removable High Pressure Interior Nozzles(2) 5HP (3.7kW), 3600RPM Sealed Ball Bearing Continuous Duty Motors (Motor meets or exceeds U.S. EPAct and NRCan Canadian efficiency standards)(2) Direct-drive aluminum airfoil wheels with superior efficiencyAverage Nozzle Velocity: 7800 FPM (39.62 m/s) Average Airflow: 3800 CFM (1.79 m3/s) Filters: (2) 24x24x11.5, 99.99% HEPA Filters
(1) Magnetic pressure gauge(8) Wall Return Air Grills with 10x20x1 MERV 8 Prefilters (2) 2-1/2 inch diameter sprinkler sleeves Programmable microprocessors
Epoxy or Urethane Sealant
(2) Safety glass doors with hydraulic door closers and anodized aluminum framesAnodized Aluminum Fixed Bottom Door Sweeps(2) LED Recessed Light Fixtures with Wall Switch, (4) LED Recessed Light Fixtures with Wall Switch for Double Door Models(64) Anodized aluminum nozzles that can be adjustedAdjustable anodized aluminum ceiling nozzles (four)(4) Wall Panels with Removable High Pressure Interior Nozzles(2) 5HP (3.7kW), 3600RPM Sealed Ball Bearing Continuous Duty Motors (Motor meets or exceeds U.S. EPAct and NRCan Canadian efficiency standards)(2) Direct-drive aluminum airfoil wheels with superior efficiencyAverage Nozzle Velocity: 7800 FPM (39.62 m/s) Average Airflow: 3800 CFM (1.79 m3/s) Filters: (2) 24x24x11.5, 99.99% HEPA Filters
(1) Magnetic pressure gauge(8) Wall Return Air Grills with 10x20x1 MERV 8 Prefilters (2) 2-1/2 inch diameter sprinkler sleeves Programmable microprocessors
