Clean Room Disinfection System

Description Program selection and intuitive controls are implemented through a touch screen interface. SIEMENS touch panel, TP700 Comfort control system

Structural material: AISI 304 stainless steel with a FIN8 grinded surface. Compression method for air supply A compressed air supply point must be accessible at the installation site. Our vapor generation process operates at standard pressure and temperatures (approximately 25 to 30 °C).

It does not leave any toxic residues, as hydrogen peroxide decomposes into oxygen and water after decontamination. The device is mobile, which means that it can be used to decontaminate surfaces in a variety of locations. It can be connected to a greater number of devices through the use of a DN50 triclamp. Option to incorporate the device into an isolator or pass-through cabin br/>
Applications

sanitation, disinfection

sterilization

inside surfaces of closed boxes (e.g. isolators and pass-through cabins)

inside surfaces of rooms

Employs a 30% concentration of hydrogen peroxide.Variants include: With an open loop system, PuriterOperational ReadinessTo ensure the proper operation of equipment, the following must be done:input:
output: Air that is under pressure According to ISO 8573.1, cleanliness is classified as "3."

Six bar of pressure

Provide a flow rate of 30-60 m3/h. Electricity supply L+N+PE / TN-S - 230V/50Hz (power supply)

Input power: 2.2 kW
