Clean Room Air Handling Unit

AIR COMPACTTM is particularly well-suited for the air conditioning of distinct zones. It necessitates low ceiling heights and is characterized by high static pressure. The collection comprises an extensive selection of housings and accessories. Indoor installation is feasible in either horizontal or vertical configurations.input:
output:Air flow rate: 1,500 to 6,000 m3/hUltra-slim AHUinput:
output:Available in either a single-flow or dual-flow configurationRange:input:
output:
The range consists of three sizes, with a thickness of 400 mm, ranging from 1,500 to 6,000 m3/h.input:
output:High performance and minimal sound levels are achieved with available pressure ranging from 100 to 1,000 Pa.input:
output:The three sizes of AIR COMPACT 25, 40, and 60 are 750 mm, 1,310 mm, and 1,880 mm in width.input:
output:Thanks to the control system, performance has been optimized.input:
output:Operating pressure: up to 1,000 psiinput:
output:Characteristicsinput:
output:This air handling unit is particularly well-suited for the air conditioning of distinct zones. It necessitates low ceiling heights and is characterized by high static pressure. The collection comprises an extensive selection of housing and accessories. Indoor installation is feasible in either horizontal or vertical configurations.input:
output:All conventional functions, including damper, opacimetric filter, water or electric heating, chilled-water or direct-expansion cooling, ventilation, mixing, distribution plenum, quiet operation, and recovery units, are included.input:
output:Horizontal units are installed on the ceiling or floor, while vertical units are mounted on the wall.input:
output:Hinged doors that can be removed,A diverse array of supplementary equipment.Benefitsinput:
output:A comprehensive selection of options that are simple to install (thickness: 400 mm)input:
output:Noise at a low levelinput:
output:A 25 mm thick mineral wool insulation is used to insulate the double-skin casing.input:
output:Galvanized steel with a coated finish is used for the external sides.
