Cardiac Telemonitoring System

The ECG data is automatically transmitted via a wireless connection by the MCOT monitor, which collects it from the sensor via Bluetooth. Despite the fact that the monitor will automatically transmit cardiac data to BioTel Heart 24 hours a day, it is crucial that you document symptoms as soon as you experience them. This will ensure that your healthcare professional has the most comprehensive information possible during your monitoring period.input:
output:Technical Specifications:Sensor Functionality:Channels: Two channels

Resolution: 12 bits

Sample Rate: 250 HzMonitor Functionality:
Touchscreen: IPS Capacitive

Android Operating SystemBattery Type: Lithium Ion 2500mA/Hr

Service Life: Three yearsSensor Physical:Dimensions: 2 inches by 1.6 inches by 0.36 inches.Weight:.069 oz (19g)

USB connection: Female micro USB

Custom 8-terminal connector for connection to patch/electrodeBattery Type: Lithium Ion Rechargeable 500 milliamperes per hour at 3.7 voltsPhysical Monitor:Dimensions: 5.06" x 2.69" x.51" Weight: 5.94 oz

Battery Type: Lithium Ion 2500mA/Hr

CDMA cellular radios: LTE Cat 3 1x EVDO, 1x Advanced

Bluetooth: 4.0 + LE/EDR

Sensor Transmission: Bluetooth RadioSensor Operating Conditions:When inserted into a patch or electrode, the IPX rating is IPX4. This rating indicates that the device is resistant to water splashes from any direction.

Operating Temperature: 10°C to +45°CNon-Operating Temperature: -20°C to +70°COperating Humidity: 10% to 95% (non-condensing)

Non-Condensing Humidity: 5% to 95%
