Cardiac Stress Test Equipment

ECG acquisition module• Stress ECG system that is cost-effective• Module for ECG acquisition by CARDIPIA ECG• CARDIPIA ECG displays real-time electrocardiogramsinput:
output:Stress ECG S/W• Automated ECG analysis and ST measurement• An automatic alarm and arrhythmia detection system• The analysis report may be reproduced or printed.• The editing and creation of a treadmill protocol for an ergometer or treadmill.Ergometer/Treadmill• Longer lifespan and reduced maintenance requirements• Movement that is both smooth and silent• Maximum speed: 20 kilometers per hour• Gradient: 25% (step 0.5%)• Maximum patient loading weight: 220 kg• Running belt dimensions: 1460 x 500 mm• Motor: 3 horsepower

• Control: via Bluetooth or RS232 (USB)• Weight: 195 kgTechnical SpecificationsRecording ECG Leads – Twelve standard leads: I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6Lead Group Standard / Cabrera / User-defined combinationRecording Mode Auto, Manual, Copy, Elapsed, Rhythm, and CalibrationRecording Channel 12 / 6+1 / 3+1 ch1-ch (lead II) / 2-ch (lead II, V5) / 3-ch (lead I, II, V5) rhythm recordThe following channels are currently being displayed: 12, 6, 4, 3, 2, and 1.Sensitivity (mm/mV) 2.5, 5, 10, 20, [40, Auto (option)Recording System – A thermal head printer with a high resolution of 8 dots per millimeter.Vertical and horizontal resolutions are 203 and 508 dpi, respectively.

Paper for recording, measuring 216 mm x 30 m A4 or Letter size thermal-sensitive roll Thermal-sensitive Z-folder type (optional)Recording length (auto) User-selected length (5–25 seconds)Simultaneous 12-lead ECG data acquisitionLatest 5 to 10 second signal record Elapsed rhythm recordFull Disclosure Report – The user selected a lead signal and recorded a compact rhythm for one minute.Alphanumeric key with touch screen keypad for patient data input Language: English, Spanish, Russian, Turkish, Korean
