Cad/Cam Milling Machine

One of the most precise standalone wet milling devices ever constructed is the DWX-42W. For applications involving glass ceramics, composite resin, PMMA, and titanium, a ball-screw-driven system that is both smooth and steady yields exceptionally precise and esthetically accurate results. The DWX-42W is capable of producing multiple dental restorations with ease by rotating and tilting pin-type material for deep undercuts, thanks to a fourth axis.



The DWX-42W provides a comprehensive solution for the milling of custom abutments from titanium blanks produced by renowned manufacturers such as DESS, NT-Trading, MEDETiKA®, and GeoMedi when used in conjunction with the AK-1 Abutment Milling System. The DWX-42W and AK-1 Abutment Milling System facilitate the production of custom titanium abutments in-house. In a matter of minutes, transition to the production of custom abutments, which eliminates the complications associated with outsourcing and improves the efficiency, convenience, and cost-effectiveness of the production process.TECHNICAL FEATURESinput:
output:Pin type (Width × depth × height): maximum 40 × 20 × 20 mm (1.5 × 0.8 × 0.8 in.)

XYZ operating speed: 6 to 1800 mm/min (0.24 to 70.9 in./min)

A: ±360° Rotary axis travel angle
Six milling burs are stored.

Milling bur with attachment: Shank diameter: 3 mm, milling bur dedicated to this purpose

Compliant compressed air is defined as 0.18 to 0.22 MPa.

Interface: USB, Ethernet (10 BASE-T/100 BASE-TX automatic switching)NC code, RML-1 control command sets

Power requirements: 2.1A, AC 100 to 240 V ± 10%, 50/60 Hz (overvoltage category: II, IEC 60664-1)

Noise level during operation: 70 dB (A) or lower (when not in use)
