Cad/Cam Milling Machine

Designed For For Dental Wax, Zirconia, For Metal, For Cobalt-Chromium, For Resin, For Dental Plaster
Applications Dental, For Dental Laboratories
Other Characteristics With Tool Management
Type Cad/Cam
Number Of Axes 5-Axis
Number Of Spindles Spindle
Configuration Benchtop
SKU: ffbe334c055b
Warning: Attempt to read property "slug" on null in /www/wwwroot/www.goldhealthtech.com/wp-includes/taxonomy.php on line 4684
Category: Tags: , ,
Description

DWX-52D 5-axis dental mill provides a cost-effective, precise, user-friendly, and highly dependable solution.

Make a diverse selection of restorations, such as crowns, copings, bridges, inlays and onlays, veneers, abutments, implant bars, screw-retained crowns, digital dentures, models, surgical guides, and bite splints.

Includes enhanced capabilities to optimize your laboratory’s efficiency and productivity, such as improved tool management, increased material compatibility, and upgraded disc handling.input:
output:A new snap-on clamp system with six included adapters for 98.5mm discs enables the rapid and secure installation of zirconia, wax, PMMA, gypsum, PEEK, glass fiber-reinforced resin, composite resin, and CoCr sinter metal materials.

When milling reinserted discs, disc material adapters preserve the original point of origin. To optimize material utilization and minimize unit costs, nest your restorations even more tightly. A pin-type material adapter allows for the sequential setting up and milling of eight pin-type blocks.input:
output:The DWX-52D offers a 15-station system that enables continuous, unattended milling.

The Automatic Tool Changer (ATC) is a device that has the following technical features:Material that can be cut: Zirconia, wax, PMMA, composite resin, PEEK, gypsum, glass fiber reinforced resin, and CoCr sinter metal.

XYZ axis: 6 to 1800 mm/min (0.24 to 70.9 in./min) at operating speed

Brushless DC spindle motor Engine

Travel angle of the rotary axis: A: ±360°, B: ±30°The number of burs that are stored is fifteen.

Attachable burr: Length: 40 to 55 mm (1.57 to 2.17 in.), Shank diameter: 4 mm

Compressed air that is compatible with this specification is between 0.02 and 0.2 Mpa.

Interface: USBPower requirements: 2.0 A, AC 100 V to 240 V ±10 %, 50/60 Hz (overvoltage category II, IEC60664-1).
