Body Fluids Suction Jar
Reference: 1092023
Surgical Instruments
| Material | Polypropylene |
| Application | Body Fluids |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
A rigid container and a lid that must be hermetically coupled prior to the commencement of suction are the components of a fully disposable system. The jar and lid are connected by a pressure seal that is secured with spring clips that are permanent. The polypropylene jars are of exceptional clarity, and the lid is equipped with a floating valve and an integrated antibacterial filter to safeguard the plant from any potential contamination. input:
output:
HDPE (high-density polyethylene) is the material used for the lid.
Jar composition: High-quality polypropylene
"VACUUM" port - female conic connector
"PATIENT" port - Ø 14.0 ÷ 15.5 (Ø 8.0 ÷ 9.2 mm with elbow connector)
"TANDEM" port - 8.0 mm / 9.2 mm
The maximum suction value is -750 mbar (-570 mmHg).Under the recommended conditions, the maximum flow rate is 42 LPM.
The maximum graduation interval is 50 ml.
Maximum length of patient hose: 2.5 meters Inner diameter: 6 millimetersminimum inner diameter of 6 mm; maximum length of 1.8 meters; supply hose size
Filtration efficiency (typical): >99.999995% with a particle size of 0.1 µm.Membrane - 100% expanded PTFE GORE™ Medical MembranePrefilter: microfiberglassNon-woven PE/PES support
output:
HDPE (high-density polyethylene) is the material used for the lid.
Jar composition: High-quality polypropylene
"VACUUM" port - female conic connector
"PATIENT" port - Ø 14.0 ÷ 15.5 (Ø 8.0 ÷ 9.2 mm with elbow connector)
"TANDEM" port - 8.0 mm / 9.2 mm
The maximum suction value is -750 mbar (-570 mmHg).Under the recommended conditions, the maximum flow rate is 42 LPM.
The maximum graduation interval is 50 ml.
Maximum length of patient hose: 2.5 meters Inner diameter: 6 millimetersminimum inner diameter of 6 mm; maximum length of 1.8 meters; supply hose size
Filtration efficiency (typical): >99.999995% with a particle size of 0.1 µm.Membrane - 100% expanded PTFE GORE™ Medical MembranePrefilter: microfiberglassNon-woven PE/PES support
