Binocular Colposcope

FD-9200C Optical Colposcope

1. Technical specifications and prerequisites:1.1 The objective lens' focal length is 300mm.1.2 objective lens magnification: continuous zoom from 0.4X to 2.75X1.3 Total magnification: 2.7 to 16.6 times1.4 Zoom ratio: 1:6.8 stepless zoom1.5 Field of View: 11mm-90mm1.6 The focal length is 20mm.1.7 Working distance: 250mm-300mm1.8 Observation mirror tilt angle: 45°1.9 *Eyepiece magnification: 10x1.10 Error in zero-sight indication: ±0.251.11 The diopter's minimum adjustment range is between +5 and -5.1.12 Interpupillary distance adjustment range: 55mm to 75mm1.13 Noise: The microscope's noise should not exceed 60 dB.1.1.14 The magnification difference between the left and right optical systems is no more than 1.5%.1.1.15* The angle of tilt between the left and right fields of view must be less than or equal to 2°.2. Camera system:2.1. Camera function: The camera is equipped with a white balance function.2. Synchronous output: the mirror image and the monitor are displayed in synchronization.The effective pixels of the HD high-definition movement are 12 million.(in order to guarantee the high definition of the digital electronic imaging system and the 100% real-time display of the mirror image, the pixels of the CCD camera can exceed 1080P. Microcomputer-controlled automatic white balance, color saturation, and other functions; 1920x1080 resolution acquisition mode;2.4. Image capture system: Image output mode: SDI/HDMI video capture, frame rate of 25 or 30 frames per second
