Beta Ray Area Dosimeter

The BAB-E air monitoring beacon is employed for national monitoring or surveillance of nuclear facilities.The BAB-E fixed beacon is employed to continuously monitor artificial Alpha and Beta aerosols in Gamma environments and in the presence of natural Radon descendants. It is equipped with a dual cover that enables it to endure the most severe climatic conditions for uninterrupted outdoor use, such as territorial surveillance and nuclear infrastructures. The DataEXPERT supervision software enables remote and real-time access to the data collected by the BAB-E.

Detector TypeDual silicon diode with a large area, 2 x 360 mm²

Energy spectrum α: From 10^(-3) to 1.10^4 Bq/m³ β: From 10^(-2) to 1.10^4 Bq/m³

Temperature range: Between +5°C and +45°C (41°F to 113°F )Adherence to the standards of the Center for Environmental Management (CEM) EMI emission: EN 61000-6-4EMI immunity: Level 3 (EN 61000-4-3)Range of measurement α: From 10-3 to 5.104 Bq/m3 β: From 10-2 to 5.104 Bq/m3Units of displayBq/m³, µGy/hVolume of sampling: 6 m³/hRelative humidityHigh humidity levels of up to 80% are possible without the formation of condensation.Index of protectionIP 55 (IP 54 for ventilation openings)AlarmsAudible and visible alarm with two adjustable alarm thresholds for the type of radiation (α or β)

CommunicationVD/VR, ShortLINK or SkyLINK (radio)

The radiation type that was detected is α and β.Detector TypeDual silicon diode with a large area, 2 x 360 mm²
