Automatic Thermosealer

The BIO25 M5-Sealer is an automatic tube sealer that is specifically designed to seal PVC tubes, particularly for sets of blood bag or plasmapheresis. The BIO25 M5-Sealer, also known as a plasmapheresis or blood bag set tube sealer, is appropriate for repeated operations at the production site to prepare blood components. A plastic cover that is easily swivelled provides adequate protection for the electrodes, facilitating the cleaning of the sealing heads.input:
output:The BIO25 M5-Sealer, a plasmapheresis or blood bag set tube sealer, is capable of safely sealing a specified number of tube segments, ranging from one to five. Subsequently, a slight twist of the sealed edges is sufficient to separate the sealed area. The operator has the ability to adjust the distance between the sealing heads within a range of 5 to 12 cm, contingent upon the desired sample volume. Depending on the type of tube, the sealing time for five segments can be adjusted from 5 to 25 seconds.Technical information is as follows:Voltage input: 230 ± 10% V, 50 Hz

220 VA maximum power consumptionSurge protection: 2 x 2.5 AT 250 V fusesSealing time: adjustable (0.25 to 5 seconds for a single head)

Frequency: 40.68 MHz

90 W/50 ohm output RF power
Dimensions in millimeters -- 560(L) x 300(P) x 200(H)Gross weight: 14.0 kilograms

Continuous OperationCE conformity standards
