Automatic Packaging Machine

Rotary sealing high-speed blister machine

. The work area is part of the cantilever construction. The pharmaceutical requirements are met through the separation of the drive and operating zones.

. It is capable of accommodating forming material reels with a diameter of up to 600mm and a waste material trimming cutter, which enables production to continue uninterrupted for approximately 90 minutes, thereby reducing the need for material replacement.

. Equipped with an integrated forming material splicer to optimize material replacement efficiency.

. The contact heating method is implemented by the upper and lower plates, which results in a substantial decrease in the forming temperature. Consequently, the power consumption, deformation of packaging material, and shrinkage are reduced.

. The positioning system is designed to facilitate an effortless format changeover by incorporating automatic format locking.

. The no-waste-trimming cutter of the window frame type conserves packaging materials.

. Utilizes a transverse cutter that effortlessly removes defective blisters and collects the blister card.

. Advanced high-precision CNC tooling machines are used to machine all of the main parts, which are composed of premium stainless steel and aluminum alloy material.

. It is possible to create a comprehensive pharmaceutical packaging line by connecting it to subsequent machines, such as High-Speed Cartoners, Stretch-Banding Machines, and Case Packers.input:
output:The primary technical parameters are as follows:Maximum Forming Area: 250×250mmMaximum Forming Depth: 12mmMaterial: Maximum width of 265mmMachine Power: 16.7 kW
