Automatic Lensmeter

Hartmann sensor with wavefront technology (117 points)input:
output:The LM-600 has significantly enhanced the measurement accuracy of vertically narrow progressive lenses by incorporating 117 points of Hartmann sensor wavefront technology.input:
output:The simultaneous measurement of power and UV/Blue lightinput:
output:It is feasible to verify the transmittance of UV/Blue light and conduct power measurements by simultaneously emitting measurement light, UV light (375nm), and Blue light (465 nm).



Support for the recognition of lens marksThe recognition of lens marks will be facilitated by the display of grid patterns on the screen. Selectable grid patterns are available.input:
output:
LAN and RS-232C connectivityinput:
output:Output the measurement data from each LAN and RS-232C port.Specificationsinput:
output:Range of Measurement

Spherical Power (SPH) ± 25D

Cylindrical Power (CYL) ± 10D

Axial angle (AXIS): 0° to 180°Additional Power (ADD) -2 to +10D

Diopter 0.01/0.06, 0.12/0.25D Prism Power 0 to 15△ Increment br/>

Prism 0.01/0.06, 0.12/0.25 △535 nm wavelength

The lens has a diameter of Ø20 to 120mm (the CL is greater than 5mm).

Quantity Object Optical lens, Contact lens, Spectacle lens

UV transmittance The wavelength's peak is 375 nm.

Blue light transmission The peak of the wavelength is 465 nm.

Touch panel color TFT display with a 7-inch widthThermal printer with a paper width of 58mmExternal Communication - Ethernet, USB3.0, and RS-232C portsinput:
output:Power Source and DimensionsDimensions: 188 mm in width, 240 mm in depth, and 430 mm in height.Weight: Approximately 5.5 kilogramsAC voltage ranges from 100V to 240V.50/60 Hz frequency

Power Consumption: 40-50 watts
