Automatic Lensmeter

The VLM-2400 is designed to measure the vertex powers, cylinder axis, prismatic power, and prism base setting within a limited area of unprocessed, processed framed, and contact lenses. The VLM-2400 also includes the capability to measure UV/BLUE transmission.input:
output:Enhances user affinity and offers a user-friendly graphical user interface and a diverse selection of modes.input:
output:Function that is convenientinput:
output:The VLM-2400 provides a 7-inch touch screen and LCD tilting for a comfortable measurement experience.input:
output:Multifunctionalityinput:
output:In addition to employing the Shack-Hartmann Wavefront Sensor to reduce measurement error and generate more precise values, the VLM-2400 incorporates a multifunction.SPECIFICATIONinput:
output:Range of Measurementinput:
output:The spherical power (SPH) ranges from -25 to +25D, with a step size of 0.01, 0.06, 0.12, and 0.25D.Cylinder Power (CYL): 0D ~ ± 10D (0.01/ 0.06/ 0.12/ 0.25D Steps) Axis (AX): 0˚ ~ 180˚ (1˚ Steps) Addition Power: 0 ~ +10D (0.01/ 0.06/ 0.12/ 0.25D Steps)Prism: 0 to 20 ΔMode of Measurementinput:
output:Cylinder Mode -, +, MIXinput:
output:Rectangular/Polar Prism ModeLED Wave 525nm (green) Wave e-Line, d-LineUV, Blue Mode 0 ~ 100%0 ~ 5△)

ETC

Siez / Weight: 5 kg, 198(W) x 245(D) x 420(H) mmTouch Panel 7-inch TFT-LCD (800×480 pixels) DisplayInternal Thermal Line Printer with Auto-Cutter FunctionMarking System Type of Ink Cartridgeinput:
output:AC 100~240V, 50/60Hz power supplyinput:
output:Power Consumption: 35-55 volts
