Automatic Esr Analyzer

The traditional standard Westergren method is characterized by a complex operation, low work efficiency, and significant cross-contamination, despite the significant guiding significance of ESR testing for numerous clinical diseases. The automatic ESR analyzer employs state-of-the-art infrared light color difference interpretation technology to automatically scan the entire process of red blood cell sedimentation within 30 minutes for the sample of the vacuum blood collection tube. To ensure the accuracy of the results, the standard curve is measured using the Westergren method.Characteristics:1. A high-resolution, user-friendly 7-inch color touch LCD screen

2. Rapid detection, 40 samples per hour (BK-ESR20), 80 samples per hour (BK-ESR40)

3. Insert sample positions for testing at any time at random.4. A thermal printer is integrated for effortless data printing.5. Temperature compensation is implemented automatically.6. Principles of advanced optical testing to mitigate reading errors in manual methods7. The test results are automatically saved by the power-off save function.Technical Parameters:Infrared detection is the method of measurement.

Analysis Outcome Westergren ESR Value (mm/hour)Type of Loading Samples may be loaded at any time, and measurements may be taken at any time. The analysis time can be set to either 30 or 60 minutes.Interval of sampling: 3 minutesMeasurement Range: 0 to 150 mm/hCompensation for Temperature The result is automatically corrected to the value at 18°C.Result Resolution: 1mm/1h and 1mm/2hBlood Level Range: 46mm to 64mmHCT Range: 0.2 to 1.0Repeatability: 0~10mm/h, SD≤1.5mm/h; >10mm/h, CV≤15%

Channel Consistency 0~10mm/h, SD≤1.5mm/h; >10mm/h, CV≤15%

Reading Accuracy: 0.2mmThe probability of a coincidence is at least 90%.7-inch color LCD touch screen display

Serial RS232 communication interface

Thermal printer integrated into the printer
