Automatic Esr Analyzer

40 channels, touch screen, large color display, and a maximum capacity of 80T/Hinput:
output:There are two methods of operation: 30 minutes or 60 minutesinput:
output:Display and print the ESR curve.Optional: barcode readerIs capable of connecting to a LIS.Details:Application area: Erythrocyte sedimentation rate analysisInfrared sensor measurement principleinput:
output:the outcome of the analysisWestergren ESR value (mm/hr)ThroughputA maximum of 80 samples per hour may be processed.Channels for reading: forty

Loading capacity: 40 samples simultaneously Loading pattern:



UnpredictableTime measurement - 30 or 60 minutes can be choseninput:
output:Sample interval: three minutesMeasurement range: (1-140)mm/hTemperature compensation - Automatically refer to 18°C (selectable)input:
output:reading resolution - ±0.1mmThe resolution of the results is 1mm/1h and 1mm/2h.- Blood level range: 50mm to 64mmDisplay: A color LCD screeninput:
output:Input: Touch screeninput:
output:Interface: RS-232 serial portinput:
output:Internal thermal recorder for printingStorage - 4,000 resultsPower supply: 50W, AC100-240V, 50-60Hzinput:
output:Operational conditions: Temperature 5°C to 40°C, humidity ≤80%input:
output:Dimensions: 365mm × 300mm × 180mm (L × W × H)Net weight: 11 kilograms
