Automatic Electrophoresis System

Mini Gel II is a comprehensive electrophoresis system that comprises all the essential components required to cast and run horizontal gels, including gel trays, combs, a digital power supply, a gel tank, and a casting stand.input:
output:The gel box lid is vented to dissipate heat during electrophoresis, and the migration tank and gel trays are molded for long service life and leakproof performance.The gel box can be cleaned by easily disconnecting the power supply.The membrane key pad's mode and arrow keys facilitate programming, and a large digital display displays all parameters.Casting sets are intended to facilitate the pouring of gels without the necessity of tape or spacers, while casting trays are equipped with numerous slots to keep combs in place.

In order to provide protection against damage, cassettes are used to contain electrodes.SPECIFICATIONSinput:
output:Sample capacity: 112 samples (4 combs)Capacity: One large gel (12,5×13 cm), two small gels (12,5×6 cm), or four micro gels (6×6 cm).

Volume of buffer tank (ml): 250

Maximum power (W): 45

Voltage input (V) Universal, AC 100-240 V, 50/60 HzOutput current range/increments (mA): 10 to 400

Output voltage (V): 10 to 150

Memory - The most recent parameters that were saved in memory.Safety: Automatic crossover, no load and load change detection, automatic crossover, microsensor (Hall effect) in power supply, no output without safety lid in place.Timer Maximum: 99 hours, 59 minutes, or continuous, with an audible alert at the conclusion of the run.Tank Dimensions (mm): 183 x 164 x 560

Unit W×L×H (mm): 245×170×620
