Automatic Blood Grouping Analyzer

blood grouping, reverse grouping, phenotyping, crossmatching, antibody screening, and antibody identification.Direct AHG test (DAT)/ single antigens/ Rh(D) Rh(CcEe)/ Newborn-ABO-Rh/ Rh/k/ ABO DD/Kell/ AHG Polyspecific/ ADK input:
output:The typical throughput is as follows:up to 96 cards per hourTransfer arm/gripper - 1 (transfer card)Pipette channels -

2 (800ul disposable plastic tips, non-conductive, low-cost, liquid level, clot, and empty tube detection) Pierce module -Twelve cards are positioned.Tips rack capacity: 384 tips (4 positions, each capable of accommodating 96 tips)Pipetting range -



Range: 10 to 800 ul/ Increment: 0.1 ulSample tube capacity:



24 samples multiplied by 6 equals 144 samples (standard tube diameter: 13mm; other diameters are available upon request)Sample types include:-


centrifuged whole blood, packed red blood cells, 3-5% and 0.8% red cell suspensions, serum, or plasmainput:
output:Reagent module -
2 X 6 = 12 blending diluent position, 96 deepwell dilution microplate, 2 dilution position, and 2 controlinput:
output:Incubation module

-

12 x 2 = 24 card positions (RT-50℃ adjustable at a 0.1℃ increment)input:
output:Centrifuge -12 x 2 = 24 card positions (maximum speed 3000r/min, centrifugal time, speed-adjustable programming)input:
output:Gel card box -The card capacity is 96, which is calculated as 24 x 4.Scanner for barcodes- 2 (1 for the gel card, 1 for the reagent and sample)A reader is a device that is used to read text.Automatic interpretation of acquisition and recognition, high-resolution image acquisition interpretation systeminput:
output:outcomes.The original image is clear and permanent, making it easy to query and track, due to the background of the backlight system.input:
output:Software -Completely intellectual property rights, humanization design, wizard-style user interface, and user-friendlyinput:
output:Evaluation and transmission of results via a bidirectional LIS/HIS connectioninput:
output:Synchronous operation and refresh of the software interface
