Automated Protein Analyzer

Locate Crystals That Are Hidden

Even Those That Are Not Visible to the EyeIdentify crystals that are concealed beneath precipitate or are not visible to the naked eye.input:
output:Be sure to catch the big hits.

Confirm the presence of sub-micron crystals

Identify crystals that are obscured in birefringent LCP, microcrystals that are less than 1 μm in size, and thin crystals.input:
output:Select the Appropriate Crystals

Differentiate Between Salt and Protein

Utilize integrated UV imaging to determine whether the crystals you have identified are protein or not.input:
output:Eliminate the uncertainty.

SONICC is capable of detecting protein crystals that are not detectable by other technologies.input:
output:The most advanced imaging technology for visualizing protein crystals, Second Order Nonlinear Imaging of Chiral Crystals (SONICC), definitively identifies crystals that are concealed beneath precipitate or submicron crystals that are invisible to the naked eye. In order to rapidly image your high-throughput crystallization plates and positively identify protein crystals, a completely automated imager is combined with two powerful technologies: Second Harmonic Generation (SHG) and Ultraviolet Two-Photon Excited Fluorescence (UV-TPEF).input:
output:Crystals are easily identifiable in murky environments due to their white appearance against a stark black background. SONICC is capable of detecting crystals that are obscured in birefringent LCP, microcrystals that are less than 1 μm in size, and extremely thin crystals.input:
output:SONICC is a highly successful, cost-effective, and efficient solution that is utilized by major pharmaceutical and academic research laboratories worldwide.input:
output:Locate Crystals That May Have Been Overlooked in the Past

Crystal detection is feasible in virtually any optical environment, including opaque and turbid environments, due to the distinctive imaging capabilities of SONICC. Second harmonic generation (SHG) is exclusively employed by chiral crystals, including proteins.
