Area Medical Alert System

Alarm device capable of managing up to 16 digital ON/OFF inputs and 6 analogue inputs (4-20mA).

It is feasible to establish two thresholds for each analogue input.

The device is equipped with an Ethernet interface for Modbus TCP/IP and an RS 485 interface for Modbus.

All parameters can be easily adjusted through the use of a PC software and USB-mini or by pressing the buttons on the alarm.

All inputs can be fully customized to meet their specific requirements.

The alarm can be configured as either a Master or a Slave.

An IP40 box is included with this equipment for external installation.

As a spare part, external IP65 or recessed IP40 are accessible.

Two output relays are available for the purpose of reporting alarm signals or controlling external devices.INTENDED FOR:Sensors (4-20mA) are utilized to monitor pressure and shut down valve boxes.

Manifolds with sensors (4-20mA) - Revised MC80

Equipment that employs sensors (4-20mA) or NO/NC technologyTECHNICAL DATAElectrical power source:24 VAC 50/60Hz +-15% / 6 VA maximum12 VDC External Battery (Optional)Inputs: 16 digital inputs (NO/NC)Six analogue inputs (4-20mA) are provided.Outlet relay: 2 (1A maximum)Outlet voltage: +12VModbus RTU data transfer: RS485

Modbus TCP/IP

Cable uses 0.75 mm of power.Modbus RTU switches are utilized for cable usage.

Alarm activation: English, Hungarian, Danish, Norwegian, Swedish, and FinnishDimensions: 178mm x 160mm x 71mmHousing: DIN box accommodating nine modules

Standards: ISO 7396-1 Medical gas pipeline systemsISO 60601-1-8 Medical electrical equipment
