Animal Research Veterinary Anesthesia Workstation

This program is a hybrid of a ventilator and anesthesia machine. The animal is maintained under anesthesia, and a specific volume of oxygen and respiratory rate are provided to facilitate the animal’s normal breathing.

It is suitable for mice, rats, rabbits, cats, and other animals weighing under 5kg, and it can accommodate the needs of long surgeries or surgeries on animals with specific diseases (e.g., hypertension, cerebral infarction, thrombosis, cardiovascular and cerebrovascular diseases).input:
output:Characteristic

1. Vaporizer with exceptional precision (Each unit is accompanied by an independent test report).

2. Dual channels: Independent switches for the chamber and mask channels.

3. Vaporizer installation is unnecessary due to the integrated design.

4. Active recycling is facilitated by a low stress induction chamber.

5. A gas evacuation system that is highly efficient in preventing the researchers from being exposed to anesthesia gas.

6. A stereotaxic anesthesia mask that does not impede experimental operations.input:
output:Air Pump:Voltage: 110-120 volts

60Hz is the frequency.

Air Flow: 18 liters per minuteAMP(A): 0.36WATT(W): 20Maximum Dimensions (mm): 163*128*111input:
output:Vaporizer:Flowmeter specifications: 0-4 liters per minute.Concentration range: Isoflurane: 0-5%; sevoflurane: 0-8%

Concentration output accuracy: ±0.1 (0-1), ±0.15 (1-1).

Capacity: ≥120 millilitersOperating temperature: 10–35°C
