Anesthetic Gas Scavenging System

The SILBERMANN Anesthetic Gas Scavenging Inlet,The non-Venturi type is intended for safe removal.excessive quantities of explosive gas mixtures and anesthetic gas from the operating room.

Its objective is to prevent the exposure of medical personnel to long-term health hazards.input:
output:The Inlet is a quick-connect type that is connected to a central AGSS system.input:
output:It is capable of withstanding pressure tests without the necessity of a specialized plug.>

BENEFITS AND FEATURES

■ Utilization of a central AGSS system for operation.

■ The vacuum flow that is necessary is guaranteed by an internal adjusting valve.

■ Extremely quiet operation

■ The probe is automatically turned off when it is disconnected.■ Quick-connect locking mechanism

■ Installation is effortless.■ Simple to maintainTECHNICAL DATA■ Inlet pressure: 3.5-5 bar

■ Outlet flow: 40 LPM• Capacity for free air suction:■ 50 LPM adjustable

■ Vacuum level: 20-50 cmH2O adjustable

■ K type exhaust pipe with a nominal length of 20 cm and an OD of 7/8″.input:
output:CONSTRUCTION MATERIAL:

■ Aluminum box: baked and painted

■ Front Panel: Aluminuminput:
output:STANDARDS THAT ARE APPLICABLE:ISO 9170-2input:
output:SILBERMANN’S QUALITY MANAGEMENT SYSTEM:■ EN ISO 13485-2016

■ ISO 9001-2015

■ CE certifiedinput:
output:STANDARDS FOR MEDICAL GAS SYSTEMS:■ ISO 7396-1■ NFPA99

■ HTM 02-01G0-1
