Anesthesia Syringe Pump

Simple, secure, and dependableinput:
output:Key features:

user-friendly software simplifies operation and setupLCD display that is both large and easily readableA broad spectrum of infusion rates is available.Volume to be infused: 0.1 – 999 ml, programmable in 0.1 ml increments Over 55 types of compatiable syringes (5-60 ml) Drug dose calculationAutomatic and manual bolus capabilities

automatic reduction of residual bolus following occlusion release

easily adjustable infusion parameters during the course of treatment

a comprehensive system of audible and visual alarms and warningsdrug library with user-selectable drug names

RS-232C interfaceLong battery life Data lock with a software-controlled passkey system br/>
4 modes of operation: flow rate, flow rate and volume, flow rate and time, and volume over time event log (up to 2000 events recorded in real time): on-screen display or as XML filePerformancesMaximum bolus rate:2000 ml/h for a 50 ml syringe 1200 ml/h for a 30 ml syringe1000 ml/h for a 20 ml syringe600 milliliters per hour for a 10-milliliter syringe

400 milliliters per hour for a five-milliliter syringe

Limited to the size of the syringe: bolus dose and induction dose

ass units of programming:The following units are available: ml/h, µg/h, mg/h, µg/kg/h, mg/kg/h, µg/kg/min, and mg/kg/min

Drug concentration: 0.01 µg/ml multiplied by 9999 mg/ml

programable in 0.1 ml/h steps, patient mass: up to 300 kg

Infusion duration: 99 hours, 59 minutes, and 59 seconds
