Air Filter
Reference: 1175116Components For The Medical Industry
| Applications | Medical, Dental |
| Fluid | Air |
| Other Characteristics | Pressure |
| Connection Type | Female |
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
OPERATION
Air Filter - Semi Automatic Drain
Filtering: 30 to 50 microns M
Maximum flow rate: 300 liters per minuteCONNECTIONSInlet: Female 1/8" NPT (ANSI B2.1). Outlet: Female 1/8" NPT (ANSI B2.1).(Kv 1,1) Flow Factor.MATERIAL Body: Aluminum (ASTM B211) with an epoxy surface. SEAL Seal: Polymer N 30000-7 B (Nitrile).
ELECTRONIC
PROPERTIES
NOT APPLICABLE
NOT APPLICABLE
NOT APPLICABLE
MAIN APPLICATIONSAir/Oxygen* Consult compatibility with other applications. br/>
PRESSURE (PSI) Min. 0 / Max. 180
SPECIAL FEATURES
Cup policarbonate material and body Zamac material.Work temperature: 60°CFlow Rate: 550 L/minDrainage: Semi-automatic
Air Filter - Semi Automatic Drain
Filtering: 30 to 50 microns M
Maximum flow rate: 300 liters per minuteCONNECTIONSInlet: Female 1/8" NPT (ANSI B2.1). Outlet: Female 1/8" NPT (ANSI B2.1).(Kv 1,1) Flow Factor.MATERIAL Body: Aluminum (ASTM B211) with an epoxy surface. SEAL Seal: Polymer N 30000-7 B (Nitrile).
ELECTRONIC
PROPERTIES
NOT APPLICABLE
NOT APPLICABLE
NOT APPLICABLE
MAIN APPLICATIONSAir/Oxygen* Consult compatibility with other applications. br/>
PRESSURE (PSI) Min. 0 / Max. 180
SPECIAL FEATURES
Cup policarbonate material and body Zamac material.Work temperature: 60°CFlow Rate: 550 L/minDrainage: Semi-automatic
