Air Filter Unit

Fan Filter Units (FFUs) are employed in numerous applications to decrease the concentration of particles in cleanroom facilities or portions of them. The fan filter units will be delivered pre-installed and are appropriate for use in cleanrooms with turbulent air flows or laminar flows up to class 3 in accordance with DIN EN ISO 14644-1. They are compatible with all Lindner Reinraumtechnik cleanroom ceilings. When necessary, fan filter units draw air in through a top-mounted prefilter or chiller and exhaust it through a high-quality filter into the cleanroom. The self-supporting casing of this fan filter unit is composed of aluminum. Provided with either mineral fiber mats or plastic foam lining for sound absorption, contingent upon their intended use. The fans are electronically commutated (EC), which results in an exceptionally high level of energy efficiency. The fan filter units can be integrated into a network and controlled and monitored via a central control unit through an interface at the drive unit.A decentralized unit that includes a motor, fan, and filter



Various control variants are available and can be combined with a heat exchanger. There are numerous sizes available and a very small footprint.an all-in-one solutionSpecificationsinput:
output:Main filter class H14input:
output:Volume: 50 dB (A)The initial pressure loss is 100 Pa.input:
output:500 watts of power consumptioninput:
output:Voltage range: 200 V to 277 Vinput:
output:Voltage Type: ACinput:
output:frequency: 50 Hz to 60 HzCurrent strength: 1.70 AWeight: 21 kg per unit - 46 kg per unit.input:
output:supplementary equipmentParticle FiltersSuperior grade glass fiber filters from U15 to U17 are available as an alternative to H14 filters.
