6-Channel Electrocardiograph
Reference: 1037828
Monitoring
| Applications | Resting |
| Options | With Printer, With Touchscreen |
| Number Of Channels | 6-Channel |
| Technology | Digital |
| Connectivity | Wireless, Wired |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
Technical indicatorsCommon mode rejection ratio: ≥100dBFloat, defibrillation comprise the input circuit.Input loop current: ≤0.1 mAsampling rate - 12 bits/1000 Hz
Mode of operation: Manual/automaticThe filter is a power frequency filter and an EMG filter.Anti-drift system - Drift filteringThe input impedance is 50 kiloohms.Patient leakage current: 10 mA
Fuse specification: T1.6A/250V Ø5×20
Recording paper specifications: thermal recording paper that is scrollable or foldable (110mm)Calibration voltage: 1 mV with a tolerance of ±3%
voltage of polarization resistance - ±500 mVTime constant: 3.2 seconds or lessFrequency response: 0.05Hz to 165HzNoise level - ≤15 mVp-pDetection signal minimum: ≤20}VThe feeding speed is as follows: 12.5 mm/s, 25 mm/s, and 50 mm/s.The sensitivity is 5 × 10 × 20 (mm/mV ±5%).Record - High-resolution thermal printing with six channelsThe battery is 10.8V/2.6Ah, which is equivalent to 28.08Wh.
Net weight: 1.85KG Overall dimensions: 320mm x 230mm x 78mmGross weight: 4.5KG Packing box dimensions: 390mm x 300mm x 215mm
Mode of operation: Manual/automaticThe filter is a power frequency filter and an EMG filter.Anti-drift system - Drift filteringThe input impedance is 50 kiloohms.Patient leakage current: 10 mA
Fuse specification: T1.6A/250V Ø5×20
Recording paper specifications: thermal recording paper that is scrollable or foldable (110mm)Calibration voltage: 1 mV with a tolerance of ±3%
voltage of polarization resistance - ±500 mVTime constant: 3.2 seconds or lessFrequency response: 0.05Hz to 165HzNoise level - ≤15 mVp-pDetection signal minimum: ≤20}VThe feeding speed is as follows: 12.5 mm/s, 25 mm/s, and 50 mm/s.The sensitivity is 5 × 10 × 20 (mm/mV ±5%).Record - High-resolution thermal printing with six channelsThe battery is 10.8V/2.6Ah, which is equivalent to 28.08Wh.
Net weight: 1.85KG Overall dimensions: 320mm x 230mm x 78mmGross weight: 4.5KG Packing box dimensions: 390mm x 300mm x 215mm
