4-Channel Platelet Aggregation System

Using light transmission aggregometry on plasma, the Helena AggRAM provides fully customizable platelet aggregation and Ristocetin cofactor testing.input:
output:Principle of detection:The transmission of light

Four-channel laser optics that operate at a wavelength of 650 nmDimensions:Aggregation

Agglutination



Sample processingPlasma sampleMicro-volume testing necessitates a minimum cuvette volume of 250 μl.Per run, there are either four or eight patient samples.
Four ambient reagent positions 12 sample incubation positionsinput:
output:The primary characteristics are as follows:Flexibility - input additional agonists, create new screens, and customize your assay test sequence, calibration, dilutions, volumes, run times, and display parameters.

Half-volume – fully optimized half-volume settings, including programmable stirrer speed

Powerful data management – automatic calculation of slope, max% aggregation, time to max aggregation, lag phase, secondary slope, and area under the curve (research use only) with full manual edit optionsSecurity - operator log-on with password-level protectionDatabase – a comprehensive database that contains patient results, quality control, and standards. Data retrieval with the assurance of a complete automatic backup

Interface: LIMS unidirectional host interface

Quality control – Levey-Jennings display of QC data based on assigned Westgard rules with an integrated corrective action log

Option for PC/printer availability
