32-Channel Eeg System

The TruScan RE Research EEG system is designed for rigorous research applications, such as TMS-EEG, tES-EEG, and NIRS-EEG. It is a portable, user-friendly device that boasts high sampling rates.TruScan Research EEG

In addition to receiving triggers from external devices, the TruScan Research EEG can stream data in real-time via UDP for Brain-Computer Interface (BCI) applications. This capability enables the investigation of the evolution of externally-triggered post-synaptic events over time. The review software enables a simple yet powerful analysis, as well as expertise in a variety of common formats, and the acquisition user interface is intuitive to use in a dashboard format.input:
output:
COMPATIBILITY

By directly integrating with the DuoMAG TMS stimulator range, the TruScan Research EEG enables users to regulate TMS parameters and automatically trigger stimuli from the EEG acquisition software. Brainsight TMS Navigation and Brainsight NIRS are also supported for integration.ACQUISITION SOFTWAREStimulator intensity, total number of TMS pulses, repetition rate (both fixed and random), and stimulator recharge delay are all controllable by the acquisition software that is included.input:
output:CHANNELSThe TruScan Research EEG is capable of supporting a 3kHz sampling rate and up to 128 channels. The recovery time is as follows:

An unparalleled recovery time of 2 milliseconds for TMS artifacts.
