3-Channel Veterinary Ecg System
Reference: 1077421
Veterinary Office
| Number Of Channels | 1-Channel, 3-Channel, 12-Channel, 6-Channel |
| Options | Usb, With Touchscreen |
Associated tags
Documentation request
Ask which specifications, manuals, or commercial documents are available for review.
Supplier coordination
Discuss quantity, destination, packaging, and timing before confirming suitability.
Product information
Product summary
It is intended for the ECG testing of adult and pediatric patients in all health care facilities by trained personnel. The test can be recorded in either manual or automatic mode, and it is possible to conduct analysis and interpretation. The camera can be powered by either an internal battery or a 100V-240V network.input:
output:The recording of twelve standard leads.
o 12 channels in Cabrera format (aVL-I-aVR-II-aVF-III-V1-V2-V3-V4-V5-V6).
The following types of examinations are available: manual, automatic, and automatic to clipboard.
Depending on the settings, the ECG signal is automatically recorded from all 12 leads simultaneously and saved to temporary memory. The result of the examination is printed, analyzed, interpreted, or saved to a database.
The automatic examination recording duration is adjustable, with an interval of 6–30 seconds.The electrocardiogram (ECG) is printed directly from the electrocardiograph using a PCL5/6 printer.
Database output. The ability to print out supplementary information regarding the patient or examination.
Functional soft-key keyboard with alphanumeric and numerical keys.
It is feasible to establish parameters such as the printing intensity, speed, and sensitivity.
Touch panel operation is facilitated by the menu that is displayed on the screen.
Patient and examination database. Internal memory can accommodate up to 1000 patients and 1000 examinations.
Viewing the memory-stored examinations on the display, with the ability to adjust the number of leads, augmentation, and speed.
Automated analysis and interpretation in accordance with EN 60601-2-51
(CSE database) - The analysis and interpretation of a patient are contingent upon their age and sex.
output:The recording of twelve standard leads.
o 12 channels in Cabrera format (aVL-I-aVR-II-aVF-III-V1-V2-V3-V4-V5-V6).
The following types of examinations are available: manual, automatic, and automatic to clipboard.
Depending on the settings, the ECG signal is automatically recorded from all 12 leads simultaneously and saved to temporary memory. The result of the examination is printed, analyzed, interpreted, or saved to a database.
The automatic examination recording duration is adjustable, with an interval of 6–30 seconds.The electrocardiogram (ECG) is printed directly from the electrocardiograph using a PCL5/6 printer.
Database output. The ability to print out supplementary information regarding the patient or examination.
Functional soft-key keyboard with alphanumeric and numerical keys.
It is feasible to establish parameters such as the printing intensity, speed, and sensitivity.
Touch panel operation is facilitated by the menu that is displayed on the screen.
Patient and examination database. Internal memory can accommodate up to 1000 patients and 1000 examinations.
Viewing the memory-stored examinations on the display, with the ability to adjust the number of leads, augmentation, and speed.
Automated analysis and interpretation in accordance with EN 60601-2-51
(CSE database) - The analysis and interpretation of a patient are contingent upon their age and sex.
