24-Channel Eeg System

iWorx EEG SystemThe IX-EEG recorder and the LabScribe acquisition and analysis software, which includes the EEG analysis module, comprise the EEG system.input:
output:The IX-EEG is a 24-channel recorder that can simultaneously measure 20 channels of EEG, two Bio Potential Channels, a GSR Channel, and an Event Marker from a single human subject.input:
output:A 10-20 system EEG cap with Silver-SilverChloride electrodes is employed to record the EEG. The recorder is equipped with the EEG Analysis Module of LabScribe3 Software and can be directly connected to a USB port on either a Macintosh or Windows computer. Snap-leads are used to connect the EEG and GSR electrodes to pre-gelled Ag/AgCl electrodes on the subject.input:
output:An EEG cap, such as the A-EEG-CAPSYS, is necessary for the IX-EEG.input:
output:The system is appropriate for recording and measuring:

■ Event-Related Potentials in ERP

■ EDA: Electrodermal Activity (Skin Conductance)■ EEG: Electroencephalography■ EMG: Electromyography■ ECG: Electrocardiogram■ EOG: Electro-oculogram



IX-EEG Specifications

Recorder

• A 10-20 EEG cap is used to record 19 channels of EEG.

(Ag-AgCl electrodes are advised.)• Two biopotential channels for ECG, EMG, EOG, and other applications.• One GSR or skin conductance channelAnalog Inputs • One Event Marker ChannelInput Range: • ±180 mV • <1 uV p-p input shorted noise at 100 s/secSystem noise • Shorted noise at 500 s/sec of <2 uV per p-p inputMontages • Software-defined by the userSoftware • LabScribe™ Recording and Analysis Software
