2-Section Tilt Table

A multifunctional tilt table that can be converted into a two-section examination couch. This model is equipped with central locking castors, a harness set, a patient worktable, and hand grips.input:
output:Max. safe working load and lifting capacity: 225 kg (495 lbs)A central locking and steering facility, as well as a large mobile wheel design.Hand switch control for electric height and tilting operationThe head section facility can be adjusted from 0˚ to +75˚ using either gas assisted or electric power.
Dual foot boards with adjustable angles from +15˚ to -30˚ (4 Positions)
Height range: 47cm to 101cmThe angle of the tilt table is between 0˚ and +90˚.
Reduces to wheelchair height to facilitate patient transfer

Equipped with a standard tilt angle inclinometer.All pivot points are equipped with precision bearings that are specifically designed for this purpose.Clearance beneath the frame for the mobile hoistHandgrips, a set of harnesses, and a patient worktable are included.Selection of upholstery colors, either Standard or Standard+
