2-Channel Syringe Pump

The two single channels are operated independently.There are three operational modes: rate mode, time-volume mode, and dosage-weight mode.

Freely stackable: Users have the ability to freely stack one syringe pump onto another to provide a variety of solutions that have a broad range of clinical applications.

The operational status is indicated on a substantial LCD screen.KVO and Bolus functions.

The most recent infusion rate is automatically saved in the event of an unexpected switch-off.

Transfer the message between the Nurse-call System and the pumps.input:
output:Technical parametersinput:
output:
HYZ-810TU Special Function With the assistance of a drug library

Mechanical precision: Within ±2% Flow rate accuracy: Within ±3% (after accurate calibration)

Bolus Rate:50/60 milliliters Syringe: 1,200 ml/hThirty milliliters Syringe: 720 ml/h480 ml/h for a 20 ml syringe

240 ml/h for a 10-ml syringe

Purge Rate:50/60 milliliters Syringe: 1,500 ml/h
30 milliliters Syringe: 900 ml/h

20 ml syringe: 600 ml/h300 ml/h for a 10 ml syringeVolume Limit: 0.1 ml to 99,999,9 mlInjection Volume: 0.1 ml to 9999.9 ml (0.1 ml step)Occlusion:High: 800mmHg ±200mmHg (106.7kPa±26.7kPa)

Medium: 50/600mmHg ±100mmHg (66.7kPa±13.3kPa)

Low: 300mmHg ±100mmHg (40.7kPa±13.3kPa)

Alarms: Injection imminent completion, injection termination, occlusion, incorrect syringe installation, wrong setting, low battery, syringe loose, etc.Internal rechargeable Li battery with a capacity of at least 1,600mAh and a four-hour internal battery backup; AC 100V–240V, 50/60Hz

KVO rate: 1 ml/hFuse: F1AL/250/60V, two pieces includedPower Consumption: 30 wattsIP Classification: IPX1Equipment Classification: Type BF, internal power supply, Class II
