1-Channel Veterinary Ecg System

The ECG 250V machine is equipped with a high-resolution thermal printer that is capable of printing continuous 1 channel traces and annotations. The baseline is inhibited by a high-resolution digital filter and a high-frequency response (up to 150Hz).input:
output:Characteristics:Standard or European lead mode
Detection and alarm for lead-off, in the event of a battery or paper shortage

In-built ECG simulator
Automatic adjustment of the baseline to ensure optimal recording.RS232 port for the transmission of ECG data
Automatic interpretation, automatic measurementAn optional USB port is available for the transmission of ECG data.General Specifications

Safety Standard - IEC Class I, type CF

Acquisition Mode: 6 / 7 / 12 leads acquired simultaneously Input Circuit: Floating, protection against defibrillator and pacemaker12 bit A/D converter

Time Constant > 3.2 secondsFrequency Response: 0.05 Hz to 165 Hz

Sensitivity: 2.5, 5, 10, 20, 40 (mm/mV ±2%), Auto

Input impedance is 50 MO.The input circuit current is 50 nA.Calibration Voltage: 1 mV ±2%noise level: 100 decibelsThe current leakage of the patient is less than 10 µA.

Paper Speed: 6.25 / 12.5 / 25 / 50 mm/sRecording Paper - 65.62 ft (20m) roll, 2.48 in (63mm) width

AC power supply: 110/220 volts, with a built-in rechargeable battery DC power supply: 12 voltsType of Battery Dimensions: 11.61 in (295mm) x 10.24 in (260mm) x 2.36 in (60mm) Built-in rechargeable Ni-MH batteryNet Weight: 5.51 lbs. (2.5 kgs)Gross Weight: 12.13 lbs. (5.5 kgs)
