1-Channel Syringe Pump

Reference: 1075672Intensive Care
Number Of Channels1-Channel

Associated tags

No tags assigned
manage_search

Product fit review

Compare the available product information with your application and purchasing requirements.

description

Documentation request

Ask which specifications, manuals, or commercial documents are available for review.

support_agent

Supplier coordination

Discuss quantity, destination, packaging, and timing before confirming suitability.

Product information

Product summary

1.3.5-inch LCD screen for clear vision within a 5-meter radius2. Extension line grip with a unique design3. Night mode design with a single button for the patient's enhanced comfort during the night.4. Suitable for use with a variety of syringe brands, including 5, 10, 20, 30, and 50/60 ml.5. Single syringe pumps can be freely stacked to create convenient space stations in the ICU, NICU, and OT.Stackable The answer is affirmative.Infusion Modes: Rate Mode, Rate-Time, Rate-VTBI, Time-VTBI, Body WeightSecurity To guarantee a higher standard of infusion, a dual-core CPU is

Drug Library - 20-item list with drug code displayPrecision: ±2%

00:01–99:59 (Hour:Min)

Volume Range: 0 to 99,999.9 millilitersStep the flow rate by 0.1 ml/h when the rate is less than 100 ml/h, and 1 ml/h when the rate is greater than or equal to 100 ml/h.Flow Rate Range: 5 ml Syringe: 0.1 ml/h to 150 ml/h10 ml syringe 0.1 ml/h to 300 ml/h20 milliliters Syringe: 0.1 ml/h to 600 ml/h30 milliliters Syringe: 0.1ml/h-900ml/h, 50/60ml Syringe: 0.1ml/h-1200ml/h, Purge/Bolus Rate/Top Flow Rate 5ml Syringe: 150 ml/h Syringe for 10 ml: 300 ml/h Syringe for 20 ml: 600 ml/h Syringe for 30 ml: 900 ml/h Syringe for 50/60 ml: 1200 ml/hAuto Seft-Test, Syringe Dislocation, Occlusion, Near End, Syringe Empty, VTBI Completion, Low Battery, Battery Exhausted, Audible & Visible Alarms Motor malfunction, incorrect syringe specification, circuit malfunction, master CPU malfunction, monitoring CPU malfunction, parameter overlimitation, A.C. disconnection, and A.C. connectionKVO - Adjustable from 0.1 to 5.0 ml/h

Occlusion Pressure - High: - 40 KPa±20KPa Middle: - 60 KPa±20KPa Low: - 100 KPa±20KPaMaximum Infusion Pressure: 120KPa Battery Life: ≥8 hoursPower Consumption: 30 watts
