1-Channel Infusion Pump
| Type Infusion | Volumetric |
| Other Characteristics | Portable |
| Number Of Channels | 1-Channel |
| Applications | Emergency |
Opening Statementinput:
output:The product is a volumetric infusion pump that boasts a long lifespan, effortless operation, and exceptional safety. The safety of the patient and the optimal therapeutic effect are guaranteed by flow control with high accuracy and comprehensive alarm measures. >
Functioninput:
output:1) The new IV set can be calibrated to ensure infusion accuracy, and it is compatible with multiple IV set brands.
2) The 2.8″ TFT LCD will display real-time parameters, including the accumulated volume and remaining time.
3) Function for infusion reminders.
4) The infusion parameters may be retained following shutdown.
5) Implement an ultrasonic sensor with a high degree of precision (0.02 ml).
6) Elimination of the free flow condition, which prevents the free flow of liquid when the door is opened.
7) Alarm function that is both audible and visual, including occlusion, air bubble, door open, and motor failure alarms.
8) Upon completion of the infusion, it will operate at the KVO rate automatically.
9) Purging is employed to exhaust air and fill pipes.
10) Real-time pressure monitoring is facilitated by an adjustable occlusion threshold (3 grades).11) Intelligent dual-way power supply (AC, built-in high-capacity lithium battery).>
Performance◆ Type: volumetric infusion pump◆ Infusion rate: 1–699 mL/h, increment: 1 mL/h◆ Total volume: 1 to 99,999 mL, increment: 1 mL
◆ Accuracy: ±5% (use the IV set that has been calibrated)◆ Information to be displayed: residual time, accumulated infusion volume, total volume, and flow rate
â—† Safety classification: class I; type BF applied component
â—† IPX2 waterproof rating
â—† Continuous working mode
â—† Alarm functions: near end, KVO state, low battery, no power, pressure failure, door failure, air bubble, door open, occlusion, infusion reminder, and motor failure.Ultrasonic air bubble detector
• TFT: 2.8 inches
